Alphacool ES RTX 5090 Reference 1-Slot-Design with Backplate

WAK Alphacool ES RTX 5090 Reference 1-Slot-Design mit Backplate

Article no.: 10262
EAN: 4250197102629
Weight: 1,5 kg
Available: Akutell nicht Verfügbar - Mehr ist unterwegs
Images may differ slightly from the original

€299.98 *

Prices incl. VAT plus shipping costs

Liefertermin: in 4 - 5 Wochen

Alphacool hose AlphaTube TPV 12.7/7.6 - Black Matte 3.3m (10ft) retail box 330cm

€18.98*

Alphacool HF quick release coupling set TPV - Eisbaer compatible - Black

€9.98*

Alphacool HF screw-on nozzle TPV - 12.7/7.6mm straight - black - kit of 6

€16.98*

Alphacool Tec Protect 2 Clear 1000ml

€13.98*

Alphacool Core 1 Aurora Silver

€119.98*

Alphacool expands its Enterprise series with the latest 1-slot water coolers for the current... more

Close menu

Product information

Alphacool expands its Enterprise series with the latest 1-slot water coolers for the current Nvidia GeForce RTX generation. These solutions are specifically designed for use in server enclosures and workstations, enabling efficient cooling even in densely packed systems.

By employing a thin yet extremely robust carbon plate, these coolers have been designed as 1-slot units without compromising the integrity of the copper block. Paired with rear-placed brass connectors, multiple coolers can be easily stacked on top of each other or side by side within a server case. This thoughtful design saves space, simplifies tubing, and allows for seamless integration into the water circuit.

All water-bearing parts are made from high-quality copper, which offers nearly twice the thermal conductivity of aluminum. Additionally, the copper is chrome-plated rather than nickel-plated, providing extra protection for the cooler. Chrome plating is more resistant to acids, scratches, and other damage, effectively preventing the chipping of coatings.

The GPU water cooler has undergone a complete technical overhaul. To optimize cooling performance, the spacing between the cooler and the components on the PCB was redefined and tested. The water flow was simulated using state-of-the-art software and validated through practical trials. These extensive tests led to improvements in the cooler base and nozzle, ensuring the best possible cooling performance for the new Nvidia GeForce RTX generation.

Compatibility:
- Inno3D Inno3D GeForce RTX™ 5090 iChill Frostbite (C50903-32D7X-1759FB)
- Inno3D Inno3D GeForce RTX™ 5090 iChill X3 (C50903-32D7X-175967H)
- Inno3D Inno3D GeForce RTX™ 5090 X3 (N50903-32D7-17593928)

Technical data cooler
Dimensions total (L x W x H)	224,29 x 119,32 x 21,34mm
Material cooler	chrome-plated copper
Material cooler top	Acrylic
Material terminal	Acetal
Material Connection thread	Brass
Max working temperature	60°C
Pressure tested	0,8 bar
Threads	4 x G1/4"
Thickness cooler bottom	3,25mm
Thickness cooling fins	0,4mm
Distance cooling fins	0,4mm
Illumination	digital aRGB LEDs
Power connector digital aRGB LEDs	3-Pin JST
Power digital aRGB LEDs	5V
Number of digital aRGB LEDs	9
Color	transparent

Technical data backplate
Dimensions (L x W x H)	224,29 x 119,32 x 3mm
Thick backplate without spacers	1mm
Material	Aluminium

Warranty: 3 years
🔗 Warranty Terms

Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.

Technical details mehr

Technical details

Hersteller:	Alphacool
Hardware Hersteller:	NVIDIA
Anschluss:	4x G1/4"
Material Bodenplatte:	Aluminium
Abmessungen:	224,29 x 119,32 x 21,34mm
Hardware Modell:	RTX 5090
