MSI RTX 3090 TI Suprim X Alphacool water cooler

WAK Alphacool Eisblock Aurora Acryl GPX-N RTX 3090 TI Suprim X mit Backplate PHT EOL

Article no.: 13085
EAN: 4250197130851
Weight: 1,82 kg
Available: There are more than 25 units available
Images may differ slightly from the original

€77.98 * €159.98 * (51.26% Saved)

Prices incl. VAT plus shipping costs

in stock

Alphacool hose AlphaTube TPV 12.7/7.6 - Black Matte 3.3m (10ft) retail box 330cm

€18.98*

Alphacool HF screw-on nozzle TPV metal - 12.7/7.6mm straight - black - kit of 6

€27.98*

Alphacool Rise Aurora 140mm fan (140x140x25mm)

€15.98*

Alphacool NexXxoS HPE-20 Full Copper 240mm Radiator

€75.98*

Alphacool Tec Protect 2 Clear 1000ml

€13.98*

Alphacool Rise Flat Reservoir D5 with VPP Apex pump

€99.98*

The Alphacool Eisblock Aurora Acryl GPX graphics card water cooler with backplate combines style... more

Close menu

Product information

The Alphacool Eisblock Aurora Acryl GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and extensive digital RGB lighting are what set it apart. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a major development of the previous Alphacool graphics card water cooler, which has been improved in every area.

More performance!
When developing the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. In the first step, the cooler was brought closer to the individual components by reducing the thickness of the thermal pads. In the second step, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimization of the water flow within the cooler. Result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly.

Brilliant design!
The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooling block. The effect is lighting that encloses the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light scattering in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler a very unique visual touch.

Copper or aluminum?
Alphacool only uses copper in its water coolers. The Eisblock Aurora Acryl GPX has nickel-plated copper. Compared to previous models, Alphacool has improved the type of nickel plating, which has significantly increased acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminum? Copper has almost twice the thermal conductivity of aluminum and is therefore clearly the better material for water cooling.

Other special features
The Eisblock Aurora Acrylic GPX GPU cooler has patented locking screws that sit flush with the surface of the terminal. The Alphacool logo is in the corner on the top and is also fully illuminated. The corresponding designations of the compatible graphics card manufacturers can be seen on the front of the terminal. Of course, these are also fully illuminated by the addressable digital LEDs. IN and OUT are marked by small, discreet triangles. They are easy to recognize and fit perfectly into the overall visual line of the graphics card water cooler.

Compatibility:
MSI GeForce RTX 3090 Ti Suprim X 24G, 24GB GDDR6X, HDMI, 3x DP
MSI GeForce RTX 3090 Ti Gaming X Trio 24G, 24GB GDDR6X, HDMI, 3x DP
MSI GeForce RTX 3090 Ti Gaming Trio 24G, 24GB GDDR6X, HDMI, 3x DP
MSI GeForce RTX 3090 Ti Suprim 24G, 24GB GDDR6X, HDMI, 3x DP

Technical data cooler
L x W x H	266x153x24mm
Radiator base material	nickel-plated copper
Material radiator top	Acrylic
Connections	4xG1/4
Thick cooling fins	0.6mm
Maximum operating temperature	60°C
lighting	13x digital RGB LEDs
Power connection Digital RGB LEDs	3-Pin JST
Voltage Digital RGB LEDs	5V

Technical data backplate
L x W x H	266x128x6mm
material	aluminum
Color	black

Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.

Technical details mehr

Technical details

Manufacturer:	Alphacool
Cooler type:	Complete cooler
Material base plate:	Copper
Material Lid:	Acrylic
SLI compatible:	Yes
Dimensions:	266 x 153 x 24mm
Connection:	4x G1/4"
Hardware manufacturers:	NVIDIA
Hardware model:	RTX 3090 Ti
Notice:	Compatible up to 16/13mm straight, Compatible up to 19/13mm angled
