Alphacool Core Geforce RTX 5080 Gaming Trio mit Backplate

Article no.: 10276
EAN: 4250197102766
Weight: 1,6 kg
Available: Akutell nicht Verfügbar - Mehr ist unterwegs
Images may differ slightly from the original

€199.98 *

Prices incl. VAT plus shipping costs

Liefertermin: in 8 - 9 Wochen

Alphacool hose AlphaTube TPV 12.7/7.6 - Black Matte 3.3m (10ft) retail box 330cm

€18.98*

Alphacool Eiszapfen PRO 13mm HardTube Fitting G1/4 - Chrome Sixpack

€33.97*

Alphacool Tec Protect 2 Clear 1000ml

€13.98*

Alphacool Eiszapfen 13mm HardTube compression fitting 90° rotatable G1/4 for Acryl/Brass tubes - 4pcs Set Chrome

€31.98*

Alphacool Core 1 Aurora Silver

€119.98*

Alphacool introduces its new series of graphics card water coolers for the latest Nvidia GeForce... more

Close menu

Product information

Alphacool introduces its new series of graphics card water coolers for the latest Nvidia GeForce RTX generation. Part of the Core product series, these coolers combine the highest quality with exceptional performance. Thanks to an optimized technical design, these GPU coolers deliver outstanding cooling performance.

At the heart of the cooler is a copper block, precisely milled from a single piece and complemented by a precisely crafted brass terminal with a nylon cover. A chrome finish enhances the copper cooler’s durability and provides a smoother, more radiant surface than traditional nickel plating.

The visual design of the GPU water cooler has been slightly modified. A new highlight is the Core emblem placed above the jetplate, which emphasizes its affiliation with the Core series and visually enhances the design. The series continues to feature high-quality brass connectors that ensure optimal quality and safety. The specially adapted aluminum backplate covers the entire backside of the copper cooler, ensuring a clear and uniform appearance. The acrylic, combined with aRGB lighting, allows for even and impressive illumination of the entire cooler.

The GPU water cooler has been completely overhauled technically. To optimize cooling performance, the distances between the cooler and the components of the PCB were redefined and tested. The water flow was simulated using the most advanced software and verified through practical tests. These extensive tests allowed for improvements to the cooler base and jetplate, ensuring the best possible cooling performance for the new Nvidia GeForce RTX generation.

Compatibility:
- MSI GeForce RTX™ 5070 Ti 16G GAMING TRIO OC PLUS (V531-058R)
- MSI GeForce RTX™ 5070 Ti 16G GAMING TRIO PLUS
- MSI GeForce RTX™ 5080 16G GAMING TRIO
- MSI GeForce RTX™ 5080 16G GAMING TRIO OC
- MSI GeForce RTX™ 5080 16G GAMING TRIO OC White

Technical data cooler
Dimensions total (L x W x H)	180,50 x 151,07 x 34,20mm
Material cooler	chrome-plated copper
Material cooler top	Acrylic
Material terminal	Nylon
Material Connection thread	Brass
Max working temperature	60°C
Pressure tested	0,8 bar
Threads	4 x G1/4"
Thickness cooler bottom	3,25mm
Thickness cooling fins	0,4mm
Distance cooling fins	0,4mm
Illumination	digital aRGB LEDs
Power connector digital aRGB LEDs	3-Pin JST
Power digital aRGB LEDs	5V
Number of digital aRGB LEDs	8
Color	transparent

Technical data backplate
Dimensions (L x W x H)	180,50 x 122,50 x 6,00mm
Thickness backplate without spacers	3mm
Material	Aluminium

Warranty: 3 years
🔗 Warranty Terms

Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.

Technical details mehr

Technical details

Manufacturer:	Alphacool
Material base plate:	Aluminum
Dimensions:	180,50 x 151,07 x 34,20mm
Connection:	4x G1/4"
Hardware manufacturers:	NVIDIA
Hardware model:	RTX 5080
