Alphacool Eiszapfen temperature sensor G1/4 IG/IG with AG adapter - Deep Black

  • 17363
  • 4250197173636
  • 0,035 kg
  • There are more than 100 units available
  • Images may differ slightly from the original
€15.98 *

Prices incl. VAT plus shipping costs

in stock

The Alphacool Eiszapfen temperature sensor flat G1/4" is a simple water temperature sensor that... more
Product information

The Alphacool Eiszapfen temperature sensor flat G1/4" is a simple water temperature sensor that can be easily integrated into any water loop.

Integration made easy
The temperature sensor is very compact and can be integrated into any water circuit due to its G1/4" external thread. It is simply screwed into the corresponding G1/4" connection at any position in the water loop. Due to the small screw-in depth, it is compatible with all Alphacool products with a free G1/4" connection.

Sensor
A classic NTC 10 kOhm thermistor is used as sensor. The readable temperature range is between -40 and 125°C. The cable is 40 cm long and leads into a typical 2-pin connector. Many mainboards now offer direct connection options for such sensors. Please check the manual of your mainboard. Of course there are also several external controllers that offer a connector for the sensor.

Design
The design is very simple so that the temperature sensor can be installed almost invisible in the system.



Compatibility:
G1/4" female connectors



Technical data
Dimension (H x D)17mm x 18mm
Materialbrass
Cable length40cm
Connection2-Pin
ThermistorNTC 10 kOhm
ThreadG1/4" IT
Pressure tested8 bar
Max working temperature60°C
Thread length5mm
Total screw-in depth13mm
Colordeep black

Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.

Technical details mehr
Technical details
1. Seite: G1/4" Innengewinde
2. Seite: G1/4" Innengewinde
Hersteller: Alphacool
