Alphacool ES 2U All in One Server Ausgleichsbehälter

AGB Alphacool ES 2U Reservoir VPP mit Durchfluss-/Temperatursensor

Article no.: 13741
EAN: 4250197137416
Weight: 1,381 kg
Available: Es sind weniger als 5 Artikel verfügbar
Images may differ slightly from the original

€199.98 *

Prices incl. VAT plus shipping costs

in stock

Alphacool ES Orbiter Filling Station

€399.98*

Alphacool ES Liquid GL50 (-40°C) 5000ml

€79.98*

Alphacool ES deionized water (ultrapure water) 5000ml

€69.98*

Alphacool ES 19" Open Frame Server Rack 25U Adjustable Depth

€289.98*

The Alphacool ES 2U Reservoir is a versatile reservoir optimized for use in 2U server cases. The... more

Close menu

Product information

The Alphacool ES 2U Reservoir is a versatile reservoir optimized for use in 2U server cases. The quick-release fasteners on the front ensure quick and easy maintenance. The cooling system can be continuously monitored using the integrated flow and temperature sensors. The illuminated window makes the fill level easy to read at any time.

Optimized for servers
The Alphacool All-in-One reservoir has been specially developed for 2U server cases. The device has a compact design to take up as little space as possible in the server case. Due to the quick-release fasteners on the front, the cooling system can be filled and vented quickly and easily. The illuminated window makes it possible to check the fill level in the system at any time. The Alphacool ES 2U reservoir is compatible with pumps using D5 format such as the Alphacool VPP Apex.

Integrated sensors
The reservoir has a temperature sensor that covers a measuring range of -40 to 125°C and is connected to the mainboard via a 2-pin connector. In addition, a flow sensor, which is connected via a 3-pin connector, enables continuous monitoring of the water flow in the cooling system.

Technical data
Dimensions (L x W x H) (without pump)	99.66 x 146.00 x 83.90mm
Material	Metal, acetal
Weight	1500g
Threads (front side)	2x quick-release fastener G1/4”
Threads (rear side)	1x G1/4" In \| 1x G1/4" Out
Connection flow sensor	3Pin
Connection temperature sensor	2Pin
Connection aRGB	3-Pin 5V
Pump compatibility	D5/VPP
Max working temperature	60 °C
Pressure tested	0.8 bar
Color	black

Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.
